FRONT SUSPENSION A - ARMS

REAR SUSPENSION FOR POLARIS SPORTSMAN 1000 HL 2016

SUSPENSION, FRONT SHOCK

Item numbers
REAR SUSPENSION - A16SXM95AL Polaris SPORTSMAN 1000 2016 SPORTSMAN 1000 HL SPORTSMAN 1000 HIGH LIFTER
1
2
2
2
2
3
3
3
4
4
4
4
5
6
6
7
8
8
8
8
9
10
11
12
13
14
14
15
16
18
19
1
BOLT-M10X1.5X140 HXHD FLG

7518467  

Not available
2
NUT-M10X1.5 HXFLG NYLON INS

7547313  

Not available
3
BUSHING-STANDARD ORV(10)

5439874  

Not available
4
WELD-UCA REAR LH ORANGE BURST

1017216647  

Not available
4
WELD-UCA REAR RH ORANGE BURST

1017217647  

Not available
5
FITTING LUBRICATION THREADED(1

7080433  

Not available
6
SHAFT-A-ARM 63.5MM

5137346  

Not available
7
BOLT-M10X1.5X85 HX HD FLG

7518466  

Not available
8
WELD-LCA REAR LH ORANGE BURST

1021189647  

Not available
8
WELD-LCA REAR RH ORANGE BURST

1021190647  

Not available
9
BOLT-M10X1.5X130 HX HD FLG

7518675  

Not available
10
SHAFT-PIVOT 104.9MM ZINC YEL

5137590  

Not available
11
SHAFT-A-ARM LCA 0.75 OD

5136473  

Not available
12
BUSHING-LCA 0.75 ID

5437651  

Not available
13
SHAFT-PIVOT 210.27MM ZINC YEL

5137594  

Not available
14
BUSHING-A-ARM LONG 102.36MM(10

5436973  

Not available
15
SCR-HXFL-M10X1.25X235 10.9 ZOD

7519086  

Not available
16
BUSHING-STANDARD ORV(10)

5439874  

Not available
18
NUT-M10X1.25 FLG NYLOC-OLIVE D

7547333  

Not available
19
WASHER 3/8 FW(10)

7556153  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Polaris SPORTSMAN 1000 HL 2016
