STEERING, STEERING POST ASM.

FRONT SUSPENSION A - ARMS FOR POLARIS SPORTSMAN 1000 HL 2016

REAR SUSPENSION

Item numbers
FRONT SUSPENSION A-ARMS - A16SXM95AL Polaris SPORTSMAN 1000 2016 SPORTSMAN 1000 HL SPORTSMAN 1000 HIGH LIFTER
1
1
1
1
2
2
2
2
3
3
4
4
5
5
5
6
7
7
8
8
8
9
9
9
10
10
11
11
11
11
12
12
1
WELD-UCA FRONT LH ORANGE BURST

1019808647  

Not available
1
WELD-UCA FRONT RH ORANGE BURST

1019809647  

Not available
2
WELD-LCA FRONT LH ORANGE BURST

1021187647  

Not available
2
WELD-LCA FRONT RH ORANGE BURST

1021188647  

Not available
3
RING-RETAINER EXTERNAL 1.188

7710533  

Not available
4
BALL-JOINT 8MM 5140

7061220  

Not available
5
NUT-M8X1.25C10 HX NYL DIN982 Z

7547405  

Not available
6
SCR-M8X1.25X65-HX/FL-Y CL 10.9

7519212  

Not available
7
FITTING LUBRICATION THREADED(1

7080433  

Not available
8
BUSHING-STANDARD ORV(10)

5439874  

Not available
9
SHAFT-A-ARM 63.5MM

5137346  

Not available
10
BOLT-M10X1.5X85 HX HD FLG

7518466  

Not available
11
NUT-M10X1.5 HXFLG NYLON INS

7547313  

Not available
12
WASHER-M8 FW STL THRU-HRD

7556557  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
