ENGINE, OIL SYSTEM AND OIL FILTER

ENGINE, OIL SYSTEM AND OIL PUMP FOR POLARIS SCRAMBLER 500 4X4 INTL 2009

ENGINE, OIL SYSTEM AND OIL TANK

Item numbers
ENGINE, OIL SYSTEM AND OIL PUMP - A09BG50FA (49OILPUMP08SCRAM) Polaris SCRAMBLER 500 2009 SCRAMBLER 500 4X4 INTL SCRAMBLER 500 4X4 INTL - A09BG50FA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
18
18
18
18
18
18
18
19
1
ASM-OIL PUMP

3090032  

Not available
2
ROTOR OUTER FEED

3084949  

Not available
3
ROTOR INNER FEED

3084948  

Not available
4
OIL PUMP CASE I

3090000  

Not available
5
SCREW(10)

3085535  

Not available
6
PIN DOWEL

3084955  

Not available
7
PIN DOWEL

3084954  

Not available
8
WASHER(10)

3084953  

Not available
9
BOLT&WASHER ASM.

3084962  

Not available
10
OIL PUMP CASE 3

3087265  

Not available
11
ROTOR INNER SCAV.

3084950  

Not available
12
ROTOR OUTER

3090307  

Not available
13
STRAINER UNIT OIL

3084956  

Not available
14
ASM. SCREW & WASHER(10)

3084205  

Not available
15
SHAFT PUMP

3085858  

Not available
16
GEAR-PUMP 2

3090033  

Not available
17
BOLT-FLANGE

3089505  

Not available
18
SPACER 0.8

3084959  

Not available
18
SPACER 1.0

3084960  

Not available
18
SPACER 1.2

3084961  

Not available
19
CASE #2 OILPUMP

3084946  

Not available
