DRIVE TRAIN, PRIMARY CLUTCH

DRIVE TRAIN, REAR DRIVE ASSEMBLY FOR POLARIS PHOENIX 200 2016

DRIVE TRAIN, SECONDARY CLUTCH

Item numbers
DRIVE TRAIN, REAR DRIVE ASSEMBLY - A16YAP20AF (49ATVDRIVERR09PHX) Polaris PHOENIX 200 2016 PHOENIX 200 PHOENIX 200
1
2
3
4
5
6
7
8
8
8
8
8
8
8
8
8
9
10
11
11
12
13
14
15
15
16
17
18
19
22
23
24
25
26
27
28
1
BOLT-8MM

0453814  

Not available
2
BRKT-GEARCASE

0454223  

Not available
3
BOLT-TRANSMISSION

0453505  

Not available
4
RETAINER-SIGHT GLASS TRANS

0453245  

Not available
5
BOLT-HEX WASHER

0454011  

Not available
6
WASHER-FLAT

0452337  

Not available
7
DETENT-SHIFT LEVER

0454224  

Not available
8
BOLT-HEX FLANGE

0452343  

Not available
9
SEAL-OIL

0452175  

Not available
10
COVER-TRANSMISSION

0454225  

Not available
11
PIN-DOWEL

0450142  

Not available
12
GASKET-TRANSMISSION COVER

0452334  

Not available
13
BEARING-BALL

0452346  

Not available
14
BEARING-BALL

0452347  

Not available
15
BOLT-HEX FLANGE

0452350  

Not available
16
NUT-LOCK

0452355  

Not available
17
BEARING-BALL

0452354  

Not available
18
COLLAR-GEAR SHAFT

0452351  

Not available
19
SHIM-SET

0452352  

Not available
22
O-RING

0452353  

Not available
23
SEAL-OIL

0452357  

Not available
24
BEARING-NEEDLE

0452358  

Not available
25
GEAR-SHAFT OUTPUT

0452356  

Not available
26
O-RING

0452394  

Not available
27
PLUG-OIL

0451813  

Not available
28
RETAINER-GUIDE

0454226  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
